MesaFX

[dborca]

Originally posted by ps47

can you give me a link where I can get a suitable voodoo1 glide3x.dll?
thanks..

http://falconfly.de/voodoo1.htm

http://home.swipnet.se/~w-67924/3dfxPS/ptopics.htm
http://home.swipnet.se/~w-67924/3dfxPS/files/g3dllv1.zip (experimental)

You can also try to get specific drivers from your card manufacturer (I know, for example, that Guillemot still keeps drivers for its MaxiGamer3D online).

Shogakusha is the one who managed to run MesaFX on a Voodoo1 (this thread, page 11).

Good luck!

[mcmagostini]

Hi folks.

Why is that in Quake3 , for instance, i get 138 FPS with the 3dfx
OGL ICD and "just" 114 with the Mesa one at the same configuration
driver-wise and game wise?

Still about the Stripes thingy. Whenever i set the 3d Filter quality
to high i got horizontal stripes on screen. No matter DX or OGL/Glide.
If i set to normal the stripes are gone.
I can let it to high, if i also set the FSAA to single-chip. but i get
performance drop =(
Any ideias?

Using:
WinXP PRO
Amigamerlin 3.0XP
Voodoo5 5500 PCI
TBred 1700+@3200+
512RAM 333@433 2-2-2-6

[]s
Matheus Agostini

[dborca]

Originally posted by mcmagostini

Hi folks.

Why is that in Quake3 , for instance, i get 138 FPS with the 3dfx
OGL ICD and "just" 114 with the Mesa one at the same configuration
driver-wise and game wise?

Quake has no notion of FXT1 texture compression. The 3dfx ICD maps S3TC (that quake uses) to FXT1, as opposed to Mesa, which does FXT1 for FXT1 and S3TC for S3TC. Therefore, Quake doesn't use texture compression with Mesa. Actually, Kool wrote a patch to cheat S3TC with FXT1 in Mesa, but it's not embedded into the public releases.

[mcmagostini]

Thanks for the explanation Daniel

What you say is that Mesa can do s3tc compression but the voodoos
can't we all know. Does that mean MesaFX works for other cards?
Ones that support s3tc, i.e. ?

Do you know if this patch is gonna get public someday?

Other than that. Do you have any ideias on the stripes problem
i mentioned before? It happens all the times in the given
conditions and bother me not be able to use 3d filter at high =/

TIA
[]s
Matheus.

[dborca]

Originally posted by mcmagostini

What you say is that Mesa can do s3tc compression but the voodoos
can't we all know.

The Voodoos can (specifically, the Napalm core - V4/5). Since I saw the V5 in your signature I thought that might be one of the reasons MesaFX is a bit slower in Quake.

Does that mean MesaFX works for other cards?
Ones that support s3tc, i.e. ?

Mesa works for a variety of cards. MesaFX is Mesa for Voodoos.

Do you know if this patch is gonna get public someday?

Yes, maybe... just maybe...
I am pretty reluctant in including it because FXT1 and S3TC have different compression ratios. We haven't had the time to investigate properly all the implications. That's all. However, there is a compilation define which enables the hack. Just look into mesafxev.txt at my situ.

Other than that. Do you have any ideias on the stripes problem
i mentioned before?

I'll try to look into the matter.

[koolsmoky]

Originally posted by mcmagostini
Still about the Stripes thingy. Whenever i set the 3d Filter quality
to high i got horizontal stripes on screen. No matter DX or OGL/Glide.
If i set to normal the stripes are gone.
I can let it to high, if i also set the FSAA to single-chip. but i get
performance drop =(
Any ideias?

'High' is a 2x2 box filter which uses the adjacent 2 horizontal lines to output a line. The filtering works per VSA100 chip so the borderline of the SLI bands do not get filtered properly. In SLI mode, you should use 'Normal' which is a 4x1 linear filter.

The 3D Filter Quality is the famous 3Dfx 22bit post filter which is only useful in 16bit color mode.

I'll make sure that the next release of Glide prevents this.

-KoolSmoky

[mcmagostini]

@daniel
@koolsmoky

Hey guys, I REALLY appreciate your answers.
Very nice from you both whom i admire and respect.
You could see i'm a 3dfx lover also and like to see
my baby 55k at its best form always.

@daniel
I may try to compile using the s3tc->fxt1 hack
and see what happens. I'll post the result here
when i get to do it.

Thank you very much and keep up the AWESOME work!

3dfxSalutes,
Matheus

[Ragnarok72]

Originally posted by dborca

Originally posted by mcmagostini

Hi folks.

Why is that in Quake3 , for instance, i get 138 FPS with the 3dfx
OGL ICD and "just" 114 with the Mesa one at the same configuration
driver-wise and game wise?

Quake has no notion of FXT1 texture compression. The 3dfx ICD maps S3TC (that quake uses) to FXT1, as opposed to Mesa, which does FXT1 for FXT1 and S3TC for S3TC. Therefore, Quake doesn't use texture compression with Mesa. Actually, Kool wrote a patch to cheat S3TC with FXT1 in Mesa, but it's not embedded into the public releases.

I think that might explain the weird slowdown problem I get with MesaFX and RtCW, since that's a Quake-engine based game.  I'm even more sure of it because both the 3Dfx .0761 ICD and the WGL one included with the game don't have the slowdowns, and in both cases I have S3TC enabled in the options.

[ps47]

I have tried mesafx with my voodoo2,the tested game was return to castle wolfenstein.the game runs and looks great with medium/normal settings and 800*600 resolution(25-35 FPS,sometimes drops to 15-20).however,I have encountered a bug,with lightning set to light map (high),the shiny surfaces (like steel or gold objects) are not displayed correctly (see the pic).no such problems with my voodoo3.


Image Insert:

68.6 KB



Image Insert:

66.01 KB

any ideas?

[dborca]

Originally posted by ps47

I have tried mesafx with my voodoo2,the tested game was return to castle wolfenstein.the game runs and looks great with medium/normal settings and 800*600 resolution(25-35 FPS,sometimes drops to 15-20).however,I have encountered a bug,with lightning set to light map (high),the shiny surfaces (like steel or gold objects) are not displayed correctly (see the pic).no such problems with my voodoo3.

So, you say it's working differently with the same Mesa, but with different cards? Which version of Mesa have you tried exactly? And what Glide were you using for each card?

[ps47]

I am using the same mesa for both cards (ver.14040),and the Voodoo3_4_5 glide3x.dll for the voodoo3,and the Voodoo2 glide3x.dll for the voodoo2.apart from that,the game is fast and looks very good.my voodoo2 condump:
Download Attachment: voodoo2mesa.doc
6.96 KB

btw,hitman contracts (hitman3) wont work with mesafx,it just crashes to desktop(I will try to get an error log for you).seems like the hitman1/2/3 engine has real problems with mesafx,and thats too bad,hitman2/3 would benefit from mesafx..

[dborca]

Hi,

I am breaking the (new) rule, and post a new Mesa release on my situ -- Amigamerlin is busy these days. Nothing spectacular, only wgl* sh!t fixes. I tested Hitman2 demo, and it works now.

@ps47
Might be a Glide bug, then?

-Edit: I was censored so I had to redo the post

[mcmagostini]

Sorry but i lost the link to your site.
Coul you post it here again?
I'd like to download the new Mesa.

Thx
VoodooSalutes
Matheus

[Amigamerlin]

Hi guys sorry for the delay; new MesaFx 6.1.0.4 are available for downloading on www.3dfxzone.it home page.
Bye

[dborca]

Originally posted by mcmagostini

Sorry but i lost the link to your site.
Coul you post it here again?
I'd like to download the new Mesa.

Google(dborca) -> I'm feeling lucky!

http://www.geocities.com/dborca/
